- LCD Display,
- Pure Sine Wave Output,
- Microprocessor-base digital control,
- Boost and buck AVR for voltage stabilization,
- Frequency adaptive,
- Humanized alarm system,
- Automatically dianose when start,
- Cold start,
- Intelligent battery management,
- Output overload and short circuit protection,
- Automatically charging battery at UPS off mode,
- Intelligent monitoring USB,
- Battery sealed lead acid maintenance free (VRLA),
Specification
| Model |
PS 1500 |
PS 2000 |
PS 3000 |
| Capacity |
1500VA/900W |
2000VA/1400W |
3000VA/2100W |
| AC Mode |
| Input Voltage |
220VAC +/- 25% |
| Input Frequency |
50/60Hz |
| Output Voltage(Regulation) |
200-240VAC |
| Invertor Mode |
| Output Voltage |
220VAC +/- 5% |
| Output Frequency |
50/60Hz +/- 0.1Hz |
| Output Wave form |
Pure Sine Wave |
| Output Transfer Time |
2ms |
| Physical |
| Battery Type |
12VAC 9Ah x 2 |
12VAC 9Ah x 2 |
12VAC 9Ah x 4 |
| Battery Quantity |
2 pcs. |
2 pcs. |
4 pcs. |
| Battery Backup Time |
5-15 minute (depend on Loading) |
| Physical Dimension |
D405 x W145 x H220 mm. |
D405 x W145 x H220 mm. |
D455 x W195 x H330 mm. |
| Physical Net Weight |
26 Kgs |
26 Kgs |
34.5 Kgs |
| Function Display |
LCD On Line, On Battery, Input/Output Voltage, Battery Capacity, Load Level, Fan Failure, Frequency |
| Outlet |
3+1 Sockets universal Type |
