Features/คุณสมบัติ
LCD Display
Pure Sine Wave Output
Microprocessor-base digital control
Boost and buck AVR for voltage stabilization
Frequency adaptive
Humanized alarm system
Automatically dianose when start
Cold start
Intelligent battery management
Output overload and short circuit protection
Automatically charging battery at UPS off mode
Intelligent monitoring USB
Battery sealed lead acid maintenance free (VRLA)
Specification
| Model |
PS 1500 |
PS 2000 |
PS 3000 |
| Capacity |
1500VA/900W |
2000VA/1400W |
3000VA/2100W |
| AC Mode |
| Input Voltage |
220VAC +/- 25% |
| Input Frequency |
50/60Hz |
| Output Voltage(Regulation) |
200-240VAC |
| Invertor Mode |
| Output Voltage |
220VAC +/- 5% |
| Output Frequency |
50/60Hz +/- 0.1Hz |
| Output Wave form |
Pure Sine Wave |
| Output Transfer Time |
2ms |
| Physical |
| Battery Type |
12VAC 9Ah x 2 |
12VAC 9Ah x 2 |
12VAC 9Ah x 4 |
| Battery Quantity |
2 pcs. |
2 pcs. |
4 pcs. |
| Battery Backup Time |
5-15 minute (depend on Loading) |
| Physical Dimension |
D405 x W145 x H220 mm. |
D405 x W145 x H220 mm. |
D455 x W195 x H330 mm. |
| Physical Net Weight |
26 Kgs |
26 Kgs |
34.5 Kgs |
| Function Display |
LCD On Line, On Battery, Input/Output Voltage, Battery Capacity, Load Level, Fan Failure, Frequency |
| Outlet |
3+1 Sockets universal Type |
| |
|
|
|
