Card |
ID Card (Optional) |
Communication |
Bluetooth (Optional) |
Material |
Zinc Alloy (ML10 Series)
ABS Plastic (PL10 Series)
|
Backset |
60mm or 70mm (Adjustable)- American Single Latch;
62 mm - German Standard Mortise
|
User Capacity |
Admin -10; Normal User - 60; Temporary User - 20 |
Power Supply |
4 ×AA Alkaline Battery |
Operating Temperature |
0°C - 55°C |
Battery Life |
Over 6000 Times (Approx1 year) |
Backup Unlocking Way |
Mechanical Key & 9V Battery |
Door Thickness |
30-53 mm (Standard) |
Dimensions (W*L*D ) |
Front - 69*155*35 mm
Back - 69*155*25 mm
|
* ML10R/PL10R only support MF card function |
